AUO T850QVN03.4 CELL Mechanical Details

• Number of Pixel
• 3840(RGB)×2160, UHD
• Arrangement
• RGB Vertical Stripe
• Dot Pitch(W×H)
• 0.1625×0.4875 mm
• Pixel Pitch(W×H)
• 0.4875×0.4875 mm [52PPI]
• Active Viewing
• 1872(W)×1053(H) mm
• Overall Dim.
• 1884(W)×1067(H) mm
• Bezel Opening
• -
• Overall Depth
• 1.4 (Typ.) mm
• Form Shape
• Flat Rectangle
• Orientation
• Landscape type
• Aspect Ratio(W:H)
• 16:9
• Plate Thickness
• 0.50+0.50 mm
• Mass
• 6.19Kgs (Typ.)
• Surface
• Antiglare (Haze 2%), Hard coating (2H)

AUO T850QVN03.4 CELL Optical Details

• Luminance
• 0 cd/m²
• Contrast Ratio
• 6000:1 (Typ.) (Transmissive)
• Good View at
• Symmetry
• Response Speed
• 8 (Typ.)(G to G) ms
• Viewing Angle
• 89/89/89/89 (Typ.)(CR≥10)
• Operating Mode
• AMVA3, Normally Black, Transmissive
• Chromaticity
• Wx:0.287; Wy:0.335
• Support Color
• 1.07B (8-bit + Hi-FRC)
• Color Temperature
• 7910K
• White Variation
• -
• NTSC Ratio
• 71%
• sRGB
• 88% coverage
• Adobe RGB
• 74% coverage
• DCI-P3
• 73% coverage
• Rec.2020
• 53% coverage
• Remarks
• sRGB (Rec.709, BT.709), Rec.2020 (BT.2020)
• Outdoor Visibility
• No
• Transmissivity
• 5.5% (Typ.)(with Polarizer)

AUO T850QVN03.4 CELL Electronics Details

• Refresh Rate
• 60Hz
• Reverse Scan
• No
• Driver IC
• COF Built-in 12 source chips

AUO T850QVN03.4 CELL Packing Details
